ZWY50 Wheel Belt Small Type Mucking Loader
Model: ZWY50
ZWY 50 Mucking loader with the loading capacity with 50m3/hour. It can be equipped with hydraulic roller and diesel walking system. It usually applied in the tunnel or mining for dig ores.
Production ability: 50m3/h
Operation slope: less than 5 degrees
Voltage: 380, 415, 440v or as requested
Application tunnel size: big or equal than 1.8m*1.8m
Technical Specifications and Operation videos
Index | ZWY-1.2-50 |
Loading capacity | ≤50 |
Total weight | 2800±200 kg |
Wheelbase | 1250mm |
Gauge | 1120mm |
Minimum turning radius | ≤4m |
Minimum ground clearance | 180mm |
Digging width | 2200mm |
Digging depth | 260mm |
Digging height | 1750mm |
Digging distance | 1600mm |
Unloading height(customizable) | 1250mm |
Unloading distance(customizable) | 1350mm |
Gradeability | ±6(hard ground)° |
Conveyor belt speed | 0.8/0.63 |
Total motor power | 11+5.5kw |
Main motor power | 11kw |
Electric drum power | 5.5kw |
Fan power | 0.2kw |
Walking speed | 3m/s |
Rated operating pressure | 15pa |
Dimensions | 5000*1350*1500±50 |
Adapation dimension | 1.8*1.8 |
Structure and Drawings of the ZWY50 Mucking loader
Cases and shipment view
- Contact us now for more details!
